DMG 3200/3100/3000 – User Manual
Page 232 (306)
Mode 9
2x Wide SD, 2x VGA
Mode 10
2x Wide SD, 4x Half SD
Mode 11
4x SD
Mode 12
2x SD, 2x VGA
Mode 13
3x SD, 3x Half SD
Mode 14
5x VGA
Mode 15
4x VGA, 2x Half SD
Mode 16
7x Half SD
The modes listed above are defined by:
Category
Max Resolution in Category
Comment
HD
1920x1080p25
HD (25 frames per second)
1280x720p50
Broadcast HD
Half HD
960x1080p25
Half H-res HD
1280x720p25
Half frame rate Broadcast
HD
Wide SD
1024x576p25
16:9 SD
SD
720x576p25
Broadcast SD (progressive)
If a single use case or path alone is not enough to produce all the required profiles, use the
GOP alignment feature present in the Source page to combine several paths.
More profile information is available in the GUI at Edit->MS Transcoder->Screens->Use
case ->Click on? (Question mark) as shown in below figure.
Then page with multiscreenUserGuide will come up.
