DMG 3200/3100/3000 – User Manual
Page 58 (306)
• 0.25
• 0.35
Acquisition range
Select one of the following options:
• Auto
• 1 MHZ
• 2 MHZ
• 2.5 MHZ
• 5 MHZ
Spectrum
Inversion
The following options are available:
• Auto
• Normal
• Inversed
T2MIDe-encapsulation
T2 de-encapsulation specifies to extract one PLP from T2MI stream
T2MI PID
This is T2MI stream PID
T2MI PLP
This is T2MI stream PLP ID of the requires stream
Preferred PCR pid
This allows you to set a PCR PID in the input multiplex as a priority
to use for de-jittering. If this PID is not available, then the next valid
detected PCR will be used. This is only valid for transparently
mapped streams.
CBR if transparent
This de-jitter mechanism will use the incoming CBR total bitrate as a
guide for the clock source of the stream. This is only valid for
transparent mapped and PID imported outputs.
Reduced input buffer size
Enable or disable Reduced Input Buffer for introducing a low latency
dejitter function.
To monitor any of the demodulated DVB-S/S2 input signals, one of the DVB-S/S2 input ports
can be assigned to the output ASI monitor interface. The demodulated DVB-S/S2 input signal
will then be copied onto the monitor port for further analyzing or monitoring of the transport
stream. Normal operation will not be affected if the monitoring port is used.
Refer to the general input analysis description at the start of this chapter to analyze the input.
Click on the letter representing the input channel (A, B, C or D) to display the status parameters
for the specific input port. The resulting display is shown in the figure below.
