DMG 3200/3100/3000 ā User Manual
Page 59 (306)
Figure 5.18 ā DVB-S/S2 Status View
The following information is displayed:
Sync
MPEG sync number: 188 or 204
Effective Bitrate
Effective bitrate of the input stream
Total Bitrate
Total bitrate of the input stream
Input Power
Input power for the DVB-S/S2 signal in dBm
EbNo
Energy per bit/(Noise per 1Hz BW)
BER
Bit Error Rate
SNR
Signal to Noise Radio, indicated in dB
Carrier Offset
Carrier offset
Actual Frequency
Frequency reported by the demodulator
Actual Symbolrate
Symbol rate reported by the demodulator
Actual Modulation
Modulation reported by the demodulator
Lock Status
Lock status of the tuner
The status parameters EbNo and SNR will be 0 when the tuner is not locked.
In this dialog, additional parameter is present with only DVB-S Modulation:
