DMG 3200/3100/3000 – User Manual
Page 79 (306)
FEC Matrix Rows
(D)
Number of rows in the FEC matrix of the incoming stream
FEC Matrix
Columns (L)
Number of columns in the FEC matrix of the incoming stream
The combination of Unrecoverable Packets, Recovered Packets, and FEC RTP Errors is a
good indication of network quality.
5.4.5.5 Adding a New Input Stream
In the Input Control pane add the multicast/unicast IP address and port. Click Add. The input
module will now issue an IGMP join request for the selected multicast and start to analyze the
incoming stream. The service found on the selected multicast will be listed in the service view in
the lower part of the input page.
5.4.5.6 Removing a Multicast Input
Select the input to be removed by clicking on the check box on the left of the input entry (in the
Existing IP Inputs pane).
Click the Remove button in the Remove section to remove a selected input.
Please note that you can only remove inputs that are currently not in use. To delete these
streams, the associated output service must first be removed/disabled.
5.4.5.7 T2MI De-encapsulation
The following additional information is displayed in edit option for Dual IP modules configured in
dip-t2mi-decap mode.
T2MIDe-encapsulation
T2 de-encapsulation specifies to extract one PLP from T2MI stream
T2MI PID
This is T2MI stream PID
T2MI PLP
This is T2MI stream PLP ID of the requires stream
