Simplex 4100ES Installation Guide

19
Figure C-2. The Remote Unit Interface Card ...................................................................... C-4
Figure C-3. The RIC II Card................................................................................................ C-5
Figure C-4. Installing the RUI Motherboard in the CPU Bay............................................... C-7
Figure C-5. Installing the RIC II Motherboard into a 4100 Expansion Bay.......................... C-8
Figure C-6. Power and Communication Wiring for the Transponder Cabinet (4100) ....... C-10
Figure C-7. MINIPLEX Wiring........................................................................................... C-12
Figure G-1. Earth Fault Example .........................................................................................G-8
List of Figures

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
