General-purpose timers (TIM15/TIM16/TIM17) RM0440
1422/2126 RM0440 Rev 4
30.8.2 TIMx control register 2 (TIMx_CR2)(x = 16 to 17)
Address offset: 0x04
Reset value: 0x0000
Bit 1 UDIS: Update disable
This bit is set and cleared by software to enable/disable UEV event generation.
0:UEV enabled. The Update (UEV) event is generated by one of the following events:
– Counter overflow/underflow
– Setting the UG bit
– Update generation through the slave mode controller
Buffered registers are then loaded with their preload values.
1:UEV disabled. The Update event is not generated, shadow registers keep their value
(ARR, PSC, CCRx). However the counter and the prescaler are reinitialized if the UG bit is
set or if a hardware reset is received from the slave mode controller.
Bit 0 CEN: Counter enable
0: Counter disabled
1: Counter enabled
Note: External clock and gated mode can work only if the CEN bit has been previously set by
software. However trigger mode can set the CEN bit automatically by hardware.
1514131211109876543210
Res. Res. Res. Res. Res. Res. OIS1N OIS1 Res. Res. Res. Res. CCDS CCUS Res. CCPC
rw rw rw rw rw
Bits 15:10 Reserved, must be kept at reset value.
Bit 9 OIS1N: Output Idle state 1 (tim_oc1n output)
0: tim_oc1n=0 after a dead-time when MOE=0
1: tim_oc1n=1 after a dead-time when MOE=0
Note: This bit can not be modified as long as LOCK level 1, 2 or 3 has been programmed
(LOCK bits in TIMx_BKR register).
Bit 8 OIS1: Output Idle state 1 (tim_oc1 output)
0: tim_oc1=0 after a dead-time when MOE=0
1: tim_oc1=1 after a dead-time when MOE=0
Note: This bit can not be modified as long as LOCK level 1, 2 or 3 has been programmed
(LOCK bits in TIMx_BKR register).
Bits 7:4 Reserved, must be kept at reset value.
Bit 3 CCDS: Capture/compare DMA selection
0: CCx DMA request sent when CCx event occurs
1: CCx DMA requests sent when update event occurs
Bit 2 CCUS: Capture/compare control update selection
0: When capture/compare control bits are preloaded (CCPC=1), they are updated by setting
the COMG bit only.
1:When capture/compare control bits are preloaded (CCPC=1), they are updated by setting
the COMG bit or when a rising edge occurs on tim_trgi (if available).
Note: This bit acts only on channels that have a complementary output.
Bit 1 Reserved, must be kept at reset value.
