RM0440 Rev 4 1439/2126
RM0440 General-purpose timers (TIM15/TIM16/TIM17)
1445
30.8.17 TIMx input selection register (TIMx_TISEL)(x = 16 to 17)
Address offset: 0x5C
Reset value: 0x0000 0000
30.8.18 TIMx alternate function register 1 (TIMx_AF1)(x = 16 to 17)
Address offset: 0x060
Reset value: 0x0000 0001
Refer to Section 30.4.2: TIM15/TIM16/TIM17 pins and internal signals for product specific
implementation.
Bits 7:0 DTGF[7:0]: Dead-time falling edge generator setup
This bit-field defines the duration of the dead-time inserted between the complementary
outputs, on the falling edge.
DTGF[7:5]=0xx => DTF=DTGF[7:0]x t
dtg
with t
dtg
=t
DTS
.
DTGF[7:5]=10x => DTF=(64+DTGF[5:0])xt
dtg
with T
dtg
=2xt
DTS
.
DTGF[7:5]=110 => DTF=(32+DTGF[4:0])xt
dtg
with T
dtg
=8xt
DTS
.
DTGF[7:5]=111 => DTF=(32+DTGF[4:0])xt
dtg
with T
dtg
=16xt
DTS
.
Example if T
DTS
=125ns (8MHz), dead-time possible values are:
0 to 15875 ns by 125 ns steps,
16 us to 31750 ns by 250 ns steps,
32 us to 63us by 1 us steps,
64 us to 126 us by 2 us steps
Note: This bit-field can not be modified as long as LOCK level 1, 2 or 3 has been programmed
(LOCK bits in TIMx_BDTR register).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. TI1SEL[3:0]
rw rw rw rw
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 TI1SEL[3:0]: selects tim_ti1_in[0..15] input
0000: TIMx_CH1 input (tim_ti1_in0)
0001: tim_ti1_in1
...
1111: tim_ti1_in15
Refer to Section 30.4.2: TIM15/TIM16/TIM17 pins and internal signals for interconnects list.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res.
BK
CMP4P
BK
CMP3P
BK
CMP2P
BK
CMP1P
BKINP
BK
CMP8E
BK
CMP7E
BK
CMP6E
BK
CMP5E
BK
CMP4E
BK
CMP3E
BK
CMP2E
BK
CMP1E
BKINE
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
