RM0440 Rev 4 1675/2126
RM0440 Universal synchronous/asynchronous receiver transmitter (USART/UART)
1733
37.7.11 USART interrupt flag clear register (USART_ICR)
Address offset: 0x20
Reset value: 0x0000 0000
Bit 2 NE: Noise detection flag
This bit is set by hardware when noise is detected on a received frame. It is cleared by
software, writing 1 to the NECF bit in the USART_ICR register.
0: No noise is detected
1: Noise is detected
Note: This bit does not generate an interrupt as it appears at the same time as the RXNE bit
which itself generates an interrupt. An interrupt is generated when the NE flag is set
during multi buffer communication if the EIE bit is set.
When the line is noise-free, the NE flag can be disabled by programming the ONEBIT
bit to 1 to increase the USART tolerance to deviations (Refer to Section 37.5.8:
Tolerance of the USART receiver to clock deviation on page 1612).
Bit 1 FE: Framing error
This bit is set by hardware when a de-synchronization, excessive noise or a break character
is detected. It is cleared by software, writing 1 to the FECF bit in the USART_ICR register.
When transmitting data in Smartcard mode, this bit is set when the maximum number of
transmit attempts is reached without success (the card NACKs the data frame).
An interrupt is generated if EIE = 1 in the USART_CR1 register.
0: No Framing error is detected
1: Framing error or break character is detected
Bit 0 PE: Parity error
This bit is set by hardware when a parity error occurs in receiver mode. It is cleared by
software, writing 1 to the PECF in the USART_ICR register.
An interrupt is generated if PEIE = 1 in the USART_CR1 register.
0: No parity error
1: Parity error
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. WUCF Res. Res. CMCF Res.
ww
1514131211109876543210
Res. Res. UDRCF EOBCF RTOCF Res. CTSCF LBDCF
TCBGT
CF
TCCF
TXFEC
F
IDLECF ORECF NECF FECF PECF
www wwwwwww
w
ww
Bits 31:21 Reserved, must be kept at reset value.
Bit 20 WUCF: Wakeup from low-power mode clear flag
Writing 1 to this bit clears the WUF flag in the USART_ISR register.
Note: If the USART does not support the wakeup from Stop feature, this bit is reserved and
must be kept at reset value. Refer to Section 37.4: USART implementation on
page 1595.
Bits 19:18 Reserved, must be kept at reset value.
Bit 17 CMCF: Character match clear flag
Writing 1 to this bit clears the CMF flag in the USART_ISR register.
