130 TimeProvider 2300/2700 User’s Guide 098-00564-000 Revision A3 – July, 2013
Chapter 3
TimeProvider 2300/2700 CLI Command Set
Example 11:
To show the vlan attachments for masters of PTP client on ETH1 port:
TP2700>show ptp client vlan-attach eth1
Response 11:
PTP client port VLAN attachment : 0
Example 12:
To display the configuration of network transport type for PTP client on ETH1 port:
TP2700> show ptp client config eth1 transport
Mode width (ns) Current estimate of the main mode width of the
forward packet delay variation. The mode width
is used in both weighting and compensation.
Mode width is a good indicator of loading.
Packet Rate (pkts/s) Measured rate of SYNC packets in the forward
path and the DELAY_RESP packet in the
reverse path.
IP address Identifies the IPv4 address of the master.
Clock ID Identifies the Clock ID of the master.
Clock Class Identifies the PTP clockClass of the
grandmaster.
Clock Accuracy Identifies the clock accuracy of the grandmaster.
Time Scale Timescale whether PTP or ARB is used by the
grandmaster.
Time Source Identifies the time source of the grandmaster.
Time source is defined in Table 7 of IEEE Std
1588-2008.
Time Traceable Identifies whether the slave clock time is
traceable to the grandmaster.
Frequency Traceable Identifies whether the slave clock frequency is
traceable to the grandmaster.
Steps Removed Identifies the number of hops between this slave
clock and the grandmaster clock.
Table 3-1. PTP Client Status Descriptions
Status Parameter Description
