The current window displays the life management data of current used tool life
management and defined tool groups. The window is shown below:
Current tool state: display the current used tool life management data;
Tool number: current used tool and tool compensation number;
Group: the group where the tool is;
Life: tool life data, the specified value can be time or number of times according to the
different count N value; press to record the time or clear the times.Programming
Used: used tool life data.
Life unit: count unit of tool life, N1 is the used time (unit: minute), N0 is the used times
(unit:times) .
State： display the tool state（0－not be used，1－being used ，2－used，3－
_p04__ÜÎ_<skip）.
2) Creating and displaying tool group number
A. In tool group state display window, press , group number, , and the
system display the tool group life data, and when the group does not exist, it is defined to
the new group number( the parameter switch is ON in MDI mode).
Note: After the new group is defined,TAC-1002T will automatically define the first tool,
for example, the new defined group number is 01, the display is as follows:
B. Press to move the cursor to Defined Group Number.
C. Press or to select the group number in Defined Group Number, and to
gradually display content of each group number.
3. Definition of tool life data
There are two ways to set the tool life data:
1) compile NC programs and run the program setting;
2) input directly in the tool life management window.
1) Compile NC programs and run program setting
Command format: G10 L3
Command function: set to be the tool life manage data input mode
