Multi Pro 5800Hydraulic System Page 5 − 92
Boom Lift Cylinder Service
Figure 67
2
3
6
8
9
10
11
13
1
5
7
12
14
15
4
160 ft−lb
(217 N−m)
1. Rod end
2. Jam nut
3. Shaft
4. Internal collar
5. Head
6. Dust seal
7. Shaft seal
8. Back−up ring
9. O−ring
10. Steel ring
11. O−ring
12. Seal
13. Piston
14. Lock nut
15. Barrel
