Toro Multi Pro 5800 Service Manual

Multi Pro 5800Hydraulic System Page 5 − 90
Boom Lift Cylinders
Figure 66
1. Boom lift cylinder (2)
2. Pivot pin (2)
3. Flange nut (2)
4. Flange head screw (2)
5. Hitch pin (2)
6. Clevis pin (2)
7. Bumper (2)
8. Flat washer (2)
9. Flange nut (2)
10. Boom pivot bracket (2)
11. Boom lift manifold
12. Cylinder mount plate
FRONT
RIGHT
11
12
1
1
2
3
4
5
6
7
8
9
10
APPLY
GREASE
APPLY
GREASE
APPLY
GREASE
APPLY
GREASE
