Multi Pro 5800Hydraulic System Page 5 − 36

Traction Circuit − Traction (Piston) Pump Flow and Relief Pressure Test

RH LH

(UPPER)

(LOWER)

Figure 29

1015 PSI

.95 CID

.34 CID

.42 CID

4.5 GPM

50 PSI

CHARGE

FILTER

2.48 CID 2.48 CID

11.96:1 11.96:1

4000 PSI

250 PSI

.032”

TOW

VALVE

.032” .032”

2.48 CID

31.6 GPM

ENGINE

3100 RPM

BREATHER

SUCTION

STRAINER

TRACTION (PISTON) PUMP

GEAR PUMP

WHEEL

MOTORS

INTERNAL

CHARGE PUMP

P1 P2

FORWARD RELIEF

PRESSURE TEST SHOWN

RATED SPEED

TESTER WITH

PRESSURE GUAGE

AND FLOW METER

FORWARD

REVERSE
