Multi Pro 5800 Page 8 − 27 GeoLink Spray System
InfoCenter Display
The InfoCenter Display is a LCD device that is located
in the Operator control console. On machines with an
optional GeoLink spray system, the X25 or X30 control
console becomes the primary form of spray system con-
trol and the InfoCenter display provides limited spray
system information (spray pump, agitation, and clean
tank rinse pump status). The InfoCenter on GeoLink
machines still provides electrical system diagnostic as-
sistance for technicians. See Chapter 6 Electrical Sys-
tem in this manual for additional information.
1. Operator control console 2. InfoCenter Display
Figure 28
1
2
GeoLink
Spray System
