Toro Multi Pro 5800 Service Manual

Multi Pro 5800Page 7 − 6ExcelaRate Spray System
ExcelaRate Spray System Diagram
Figure 3
BOOM BYPASS RETURN
PRESSURE
TRANSDUCER
RELIEF
VALVE
SUCTION
FILTER
(IN TANK)
HIGH
PRESSURE
FILTER
SPRAY
PUMP
RIGHT BOOM
4 NOZZLES
CENTER BOOM
4 NOZZLES
LEFT BOOM
4 NOZZLES
FLOW METER
DRAIN
VALVE
BOOM SECTION BYPASS SHUT−OFF VALVE
AGITATION VALVE
AGITATION BYPASS
VALVE
BOOM SECTION
BYPASS VALVE (3)
BOOM SECTION
VALVE (3)
AGITATION THROTTLE VALVE
AGITATION BYPASS
MAIN TANK
PRESSURE
SUCTION
BYPASS
AGITATION
NOZZLE (4)

Toro Multi Pro 5800 Specifications

General

Brand	Toro
Model	Multi Pro 5800
Category	Paint Sprayer
Language	English
