Multi Pro 5800−DPage 3 − 8Kubota Diesel Engine
Air Cleaner
Figure 3
1. Cap
2. Hose clamp
3. Flange head screw
4. Clamp
5. Flange nut (2)
6. Bracket
7. Flange nut
8. Hose
9. Hose clamp (3)
10. Flange head screw (2)
11. Air cleaner mount
12. Flange nut (2)
13. Hose
14. Air cleaner assembly
15. U−Bolt
FRONT
RIGHT
12
13
14
15
1
2
9
9
9
3
4
5
6
7
8
10
11
