Toro Multi Pro 5800 Service Manual

Multi Pro 5800 ChassisPage 9 − 1
Chapter 9
Chassis
Table of Contents
SPECIFICATIONS 2............................
GENERAL INFORMATION 2.....................
Operator’s Manual 2..........................
SERVICE AND REPAIRS 3......................
Undercarriage Shrouds 3......................
Wheel Assemblies 4..........................
Tie Rod 5....................................
Front Wheel Hubs 6...........................
Front Spindles 8..............................
Front Suspension 10..........................
Planetary Drive Assembly 12...................
Planetary Drive Service 14.....................
Brake Cables 17..............................
Brake Assembly 18...........................
Brake Inspection and Repair 21.................
Seats 22.....................................
Console Assembly 24.........................
