Multi Pro 5800 Page 7 − 9 ExcelaRate Spray System
InfoCenter Display
The InfoCenter Display is a LCD device that is located
in the Operator control console. The InfoCenter display
provides information for the machine operator during
spray system operation and calibration, provides electri-
cal system diagnostic assistance for technicians and al-
lows input for user adjustable spray system settings.
See Chapter 6 Electrical System in this manual for addi-
tional information.
1. Operator control console 2. InfoCenter Display
Figure 4
1
2
ExcelaRate
Spray System
To Next Page
