Multi Pro 5800Chassis Page 9 − 2
Specifications
Item Description
Front Tire Pressure 20 PSI (138 kPa)
(22 x 12 − 12, 4 ply, tubeless, smooth)
(23 x 10.5 − 12, 4 ply, tubeless, turf tread − optional)
Rear Tire Pressure 20 PSI (138 kPa)
(26.5 x 14 − 12, 4 ply, tubeless, turf tread)
Front Wheel Lug Nut Torque 55 to 75 ft−lb (75 to 102 N−m)
Rear Wheel Lug Nut Torque 70 to 90 ft−lb (95 to 122 N−m)
Planetary, Brake Assembly and Wheel Motor 60 ft−lb (81 N−m)
Mounting Screw Torque
Front Wheel Toe−In 1/8 to 1/4 inch (3.2 to 6.4 mm)
Planetary Gear Drive Lubricant SAE 85W−140 wt. Gear Lube
Planetary Gear Lubricant Capacity (each wheel) 16 fl oz (0.47 l)
General Information
Operator’s Manual
The Operator’s Manual provides information regarding
the operation, general maintenance and maintenance
intervals for your Multi Pro machine. Refer to that publi-
cation for additional information when servicing the ma-
chine.
