Multi Pro 5800Hydraulic System Page 5 − 28

Traction Circuit − Charge Pressure Test

RH LH

(UPPER)

(LOWER)

Figure 22

1015 PSI

.95 CID

.34 CID

.42 CID

4.5 GPM

50 PSI

CHARGE

FILTER

2.48 CID 2.48 CID

11.96:1 11.96:1

4000 PSI

250 PSI

.032”

TOW

VALVE

.032” .032”

2.48 CID

31.6 GPM

ENGINE RATED SPEED

3100 RPM

BREATHER

SUCTION

STRAINER

PRESSURE

GAUGE

TRACTION (PISTON) PUMP

GEAR PUMP

WHEEL

MOTORS

INTERNAL

CHARGE PUMP

P1 P2

FORWARD

REVERSE
