Toro Multi Pro 5800 Service Manual

Multi Pro 5800Page 10 − 4Ultra Sonic Boom Kit (Optional)
Hydraulic Schematic
Ultra Sonic Boom Kit (Optional) Hydraulic Schematic
TRANSAXLE RESERVOIR
25 psi
100 MESH SCREEN
4.3 cid
1.625” BORE
STEERING CYLINDER
1.00” ROD
4.69” STROKE
0.26
1.75” BORE
1.125” ROD
10.06” STROKE
1000 psi
TP
RETRACT TO
RAISE
ULTRA SONIC BOOM LIFT CONTROL MANIFOLD
1. FLOWS SHOWN ARE CALCULATED AT HIGH ENGINE IDLE
3.7 GPM
SV08−20−0
LC
SH
OR
G
C2 C1 C3 C4
S2 S3
S4 S5
LEFT BOOM CYLINDER
RIGHT BOOM CYLINDER
ENGINE
3100 RPM
RATED SPEED
