Multi Pro 5800 Page 10 − 19 Ultra Sonic Boom Kit (Optional)
Service and Repairs
Ultra Sonic Boom Fuses
Fuses for the Ultra Sonic Boom system are included in
the bottom fuse block under the operator seat (Fig. 11).
Fuse Identification and Function
Fuses for the Ultra Sonic Boom system have the follow-
ing function:
Fuse 1−2 (10 Amp): Protects power supply for TEC
outputs (sonic sensors and solenoid coil S5).
Fuse 3−4 (10 Amp): Protects power supply for TEC
outputs (sonic boom light and hydraulic solenoid
coils S2 and S3).
Fuse 5−6 (10 Amp): Protects power supply for TEC
outputs (hydraulic solenoid coil S4).
Fuse 7−8 (2 Amp): Protects power supply for TEC
logic.
Fuse Testing
Remove fuses from the fuse block for testing. Fuse
should have continuity between fuse terminals.
1
2
3
4
5
1. Fuse block
2. Fuse 1−2
3. Fuse 3−4
4. Fuse 5−6
5. Fuse 7−8
Figure 11
Ultra Sonic
Boom System
