Toro Multi Pro 5800 - Schematics; Flow Diagram (Rev. A)

Multi Pro 5800Hydraulic System Page 5 − 10
Hydraulic Flow Circuits
Figure 8
Traction Circuit (Forward Shown)
Working Pressure
Low Pressure (Charge)
Return or Suction
Flow
1015 PSI
.95 CID
.34 CID
.42 CID
4.5 GPM
50 PSI
CHARGE
FILTER
2.48 CID 2.48 CID
11.96:1 11.96:1
4000 PSI 4000 PSI
250 PSI
.032”
TOW
VALVE
.032” .032”
2.48 CID
31.6 GPM
ENGINE RATED SPEED
3100 RPM
BREATHER
SUCTION
STRAINER
TRACTION (PISTON) PUMP
GEAR PUMP
WHEEL
MOTORS
INTERNAL
CHARGE PUMP
P1 P2
A B
A
B
RH LH
B
A
(UPPER)
(LOWER)
FORWARD
REVERSE
