Multi Pro 5800 Page 10 − 17 Ultra Sonic Boom Kit (Optional)

Troubleshooting Chart

The chart that follows contains suggestions that can be

used to assist in diagnosing Ultra Sonic Boom System

performance issues. These suggestions are not all−in-

clusive. Also, consider that there may be more than one

cause for a machine problem.

NOTE: When troubleshooting an electrical problem on

your Ultra Sonic Boom System, refer to information re-

garding the sonic boom light in this section.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Problem

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Possible Cause

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Light in sonic boom switch is not illu-

minated.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Sonic boom switch is in the MANUAL position.

Fuse D (2 amp) in sonic boom fuse block is faulty (all sonic boom

functions are affected).

Fuse B (10 amp) in sonic boom fuse block is faulty.

Electrical power from vehicle is not available (all sonic boom func-

tions are affected).

Sonic boom switch or circuit wiring is faulty.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

One of the boom lift cylinders will not

extend or retract.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Boom lift switch or circuit wiring for affected lift cylinder is faulty.

Boom lift control manifold solenoid coil or circuit wiring for affected

lift cylinder is faulty.

A hydraulic problem exists with the lift cylinder, boom lift control

manifold or other hydraulic component.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Neither of the boom lift cylinders will

extend or retract.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Fuse(s) in sonic boom fuse block is faulty.

Electrical power from vehicle is not available (all sonic boom func-

tions are affected).

A hydraulic problem exists with the lift cylinders, boom lift control

manifold or other hydraulic component.

The Toro electronic controller (TEC) or circuit wiring is faulty.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

The LED’s on one of the sonic boom

sensors are not illuminated.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Sonic boom sensor or circuit wiring is faulty.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

The LED’s on both of the sonic

boom sensors are not illuminated.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Sonic boom switch is in the MANUAL position.

Fuse A (10 amp) in sonic boom fuse block is faulty.

Sonic boom switch or circuit wiring is faulty.

Ultra Sonic

Boom System
