Toro Multi Pro 5800 - Charge Pump Flow Test

Multi Pro 5800Hydraulic System Page 5 − 30
Traction Circuit − Charge Pump Flow Test
Figure 24
A B
A
B
RH LH
B
A
(UPPER)
(LOWER)
1015 PSI
.95 CID
.34 CID
.42 CID
4.5 GPM
50 PSI
CHARGE
FILTER
2.48 CID 2.48 CID
11.96:1 11.96:1
4000 PSI 4000 PSI
250 PSI
.032”
TOW
VALVE
.032” .032”
2.48 CID
31.6 GPM
ENGINE
3100 RPM
BREATHER
SUCTION
STRAINER
TRACTION (PISTON) PUMP
GEAR PUMP
WHEEL
MOTORS
INTERNAL
CHARGE PUMP
P1 P2
RATED SPEED
TESTER WITH
PRESSURE GUAGE
AND FLOW METER
FORWARD
REVERSE
