Toro Multi Pro 5800 Service Manual

Multi Pro 5800 Page 6 - 1 Electrical System
Chapter 6
Electrical System
Table of Contents
GENERAL INFORMATION 2.....................
Operator ’s Manual 2..........................
To ro Electronic Controller (TEC) 2..............
Kubota Gasoline Engine
Electronic Control Unit (ECU) 3...............
Kubota Engine Electronic Components 3........
CAN- bus Communications 3...................
ELECTRICAL DRAWINGS 4.....................
SPECIAL TOOLS 5.............................
INFOCENTER DISPLAY 9.......................
InfoCenter Display Screens - ExcelaRate
Spray System 10............................
InfoCenter Display Screens - GeoLink
Spray System 11............................
Splash Screen 12.............................
Operator’s Information 13......................
Spray Areas 14...............................
Main Menu 15................................
Set Rates 16.................................
Settings 17...................................
Calibration 21................................
Service 22...................................
Diagnostics 24...............................
About 29.....................................
TROUBLESHOOTING 30........................
Starting Problems 30..........................
General Run Problems 32.....................
Operator Advisories 33........................
Using The InfoCenter
For Troubleshooting 35......................
Machine Faults 37............................
Engine Faults (Gasoline engines Only) 38........
ELECTRICAL SYSTEM QUICK CHECKS 39.......
Battery Test (Open Circuit Test) 39..............
Charging System Test 39......................
Glow Plug System Test 39.....................
Check Operation of Interlock Switches 40........
ADJUSTMENTS 41.............................
Brake Pedal Switch 41.........................
COMPONENT TESTING 42......................
Fusible Links 43..............................
Fuses (Gasoline Engines Only) 44..............
Engine Fuses 46..............................
To ro Electronic Controller (TEC) 47.............
Ignition Switch 49.............................
Indicator Lights ( Diesel Engines Only) 50........
Headlight Switch (Standard) 51.................
Spray Mode Switch
(ExcelaRate Spray Systems Only) 52..........
Speed Lock Switch 53.........................
Application Rate Switch 54.....................
Boom Lift Switches 55.........................
Spray Pump Enable and Agitation Switches 56...
Master Boom (Spray Enable) Switch 57...
.......
Boom Control Switches 58.....................
Speed Lock Coil 59...........................
Brake Pedal Switch 60.........................
Relays with Four (4) Terminals 61...............
Relays with Five (5) Terminals 62...............
Engine Relays (Gasoline Engines Only) 63.......
Traction Speed Sensor 65.....................
Hydraulic Valve Solenoid Coils 66...............
Neutral Switch 67.............................
Fuel Stop/Run Solenoid
(Diesel Engines Only) 68.....................
Glow Plug Controller (Diesel Engines Only) 69....
Fuel Pump (Gasoline Engines Only) 70..........
Fuel Pump (Diesel Engines Only) 72............
Fuel Level Sender (Gasoline Engines Only) 73...
Fuel Lever Sender (Diesel Engines Only) 75.....
Coolant Temperature Sender 76................
Oil Pressure Switch 77........................
CAN- bus Terminator Resistors 78..............
Diode Assemblies 79..........................
Resistor Assemblies 80........................
Spray System Valve Actuators 81...............
Operator Seat Switch 82.......................
Audible Alarm 83.............................
Throttle Assembly (Gasoline Engines Only) 84....
Flow Meter Sensor 85.........................
Pressure Transducer 86.......................
Horn Button (Optional) 87......................
Tank Clean Rinse Pump Switch (Optional) 88.....
Foam Marker ON/OFF Switch (Optional) 89......
Foam Marker Control Switch (Optional) 90.......
Electric Hose Reel Motor Switch (Optional) 91....
Electric Hose Reel Rate Switch (Optional) 92.....
Road Headlight Switch (Optional) 93............
Hazard light Switch (Optional) 94...............
SERVICE AND REPAIRS 95.....................
Headlights 95................................
Traction Speed Sensor 96.....................
Flow Meter Sensor 97.........................
Speed Lock Coil 98...........................
Battery Storage 99............................
Battery Care 99...............................
Battery Service 100...........................
Electrical
System
