Multi Pro 5800 Page 7 − 31 ExcelaRate Spray System
Service and Repairs
Spray System Components
1. Suction filter (in tank)
2. Spray pump
3. Relief valve
4. High pressure filter
5. Agitation valve
6. Agitation bypass valve
7. Agitation throttle valve
(shown fully open)
8. Agitation nozzle (4)
9. Flow meter
10. Boom section valves (3)
11. Boom section bypass valves (3)
12. Pressure transducer
13. Boom section bypass
shut−off valve
(shown open − manual mode)
14. Drain valve
Figure 30
11
12
13
14
1
2
3
4
5
6
7
8
9
10
TO SPRAY
BOOMS
SUCTION
PRESSURE
BYPASS
ExcelaRate
Spray System
