Multi Pro 5800−D Page 3 − 9 Kubota Diesel Engine
Removal (Fig. 3)
NOTE: For air cleaner maintenance information, see
the machine Operator’s Manual.
1. Raise passenger seat to access air cleaner assem-
bly.
2. Remove air cleaner components as needed.
Installation (Fig. 3)
IMPORTANT: Any leaks in the air filter system will
cause serious engine damage. Make sure that all air
cleaner components are in good condition and are
properly secured during installation.
1. Assemble air cleaner system. Make sure that vacua-
tor valve on air cleaner cover points downward after as-
sembly (Fig. 4).
1
2
3
4
Figure 4
1. Air cleaner housing
2. Air cleaner element
3. Air cleaner cover
4. Vacuator valve
Kubota Diesel
Engine
To Next Page
