Multi Pro 5800 Page 8 − 47 GeoLink Spray System

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Spray pump does not rotate

(Operator Advisories are not

present).

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Spray pump switch or circuit wiring are dirty, corroded or damaged.

Spray pump drive coupler is damaged.

Pump drive hydraulic motor is not engaging or is damaged (see

Chapter 5 − Hydraulic System).

GeoLink spray system is not configured correctly.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Spray operation from booms is

erratic.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Suction screen in tank is plugged.

Spray nozzle(s) are clogged or damaged.

Spray nozzles selected are inconsistent (different color/size) or

worn.

Nozzle valve or valve actuator is worn or damaged.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

No spray output from one or more

nozzles.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Hoses to nozzle(s) is pinched or kinked.

Nozzle valve or actuator for affected nozzle is not opening.

TEC output fuse for affected nozzle valves (boom section) is faulty.

Affected nozzle actuator circuit wiring is dirty, corroded or dam-

aged.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Low spray rate from one boom

nozzle.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Nozzle is clogged or damaged.

Spray nozzles selected is inconsistent (different color/size).
