Multi Pro 5800Hydraulic System Page 5 − 12
Figure 9
STEERING CYLINDER
NEUTRAL POSITION
NO PISTON MOVEMENT PISTON MOVEMENT
LEFT TURN
STEERING CYLINDER STEERING CYLINDER
PISTON MOVEMENT
RIGHT TURN
Steering Circuit
Working Pressure
Return
Flow
STEERING CYLINDER
BORE: 1.50”
STROKE: 8.50”
ROD: 0.63”
LR
STEERING
UNIT
PET
4.3 CID
STEERING CYLINDER
BORE: 1.50”
STROKE: 8.50”
ROD: 0.63”
LR
STEERING
UNIT
PET
4.3 CID
STEERING CYLINDER
BORE: 1.50”
STROKE: 8.50”
ROD: 0.63”
LR
STEERING
UNIT
PET
4.3 CID
