Zebra ZM400 Series

179
Corrective Maintenance
Printhead Cables
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
8. See Figure 57. Disconnect the ground cable from the print mechanism by removing the
screw securing it.
Figure 57 • Remove the Ground Cable Mounting Screw
1
Ground cable
2
Mounting screw
2
1
