Corrective Maintenance
Pinch Roller
384
14207L-001 A
ZM400/ZM600 Maintenance Manual
8/9/07
4.
Did you have to re
move the ol
d peel assembly
?
5.
See
Figure
243
. Notice the pems and
the mounting
slots.
Figure 243 • Rear View of Peel Assembly
If…
Then…
No
Go to
step 9
on
page
385
.
Y
es
Continue wit
h
step 5
.
1
Mounting slots (2)
2
Pems (2)
1
2
383
385
