Agilent Technologies 7500 ICP-MS

3-4
Agilent 7500 ICP-MS ChemStation Operator’s Manual
Startup, Shutdown and Status
Rear View and Control Switches
5 Turn on the instrument power switch.
The power switch is located on the front panel. The instrument now has power. And
the green light on the power switch is turned on.
Front View of the Agilent 7500
Power Switch for the
Rotary Pumps
Power Connection for the Rotary Pumps
Main Power Supply Cable
Main Power Breaker
Power Switch
