SHOW ALARMS

Syntax

SHOW ALARMS [ { ALL | CARD={ slot-list | ACTCFC | INACTCFC | ALL }

| INTERFACE={ type:id-range | id-range | ifname-list | ALL } } ] [

SEVERITY={ CRITICAL | MAJOR | MINOR | INFO | ALL } ] [ FULL ]

Description Displays alarm conditions on system components. The display is filtered according to the

given parameters and shown in a tabular output, with one alarm per row. There are 4 col-

umns of output for each alarm consisting of:

• The component the alarm is against

• A description of the fault or condition

• The severity of the alarm

• The time and date the alarm occurred.

Options The following table gives the range of values for each option that can be specified with

this command and a default value (if applicable).

Option Description Default Value

ALARMS The component that will have its alarms displayed.

ALL - all system components

CARD - The slot number for the card

ACTCFC- The acive CFC

INACTCFC- The inactinve CFC

ALL - All alarms on all system components are dis-

played.

ALL

INTERFACE Specifies the list of interfaces that may have an alarm

against them. Interfaces can be of varioust ypes like,

ETH or LAG. LAG type of interface can have more than

one physical port associated with it.

Interfaces can be queried by using 'type:id-range', 'name-

list' or 'ALL' options.

For example, 'ETH:2.0', 'ETH:2.1-2.4', where 2.0,2.1 etc

are the actual physical ports and are used as the inter-

face Id's in this representation.
