Introduction Classifier Management
Software Reference for SwitchBlade x3100 Series Switches (Access and Security)
6-12
Note: The precedence setting for classifiers should be 51 to 68 for classifiers that perform a filtering action,
with 69 used for dropping packets that do not match any of the filtering criteria.
Note: The precedence setting for classifiers that remark packets for the QoS function should be 146 to 199.
6.3.2.4 Example of configuring a Video Classifier
When there is no remarking of p-bits (default settings), the network is being configured so that the p-bits set-
tings are set by the upstream device. The user can, however, set the p-bit to a different value and place it in a
different queue. For example, multicast video traffic could be placed in a high priority by remarking the p-bit to
6 which places it in queue 7 on interfaces supporting 8 queues and on queue 3 on interfaces supporting 4
queues. The example will show it being placed in queue 4. The user can create the classifier as follows:
• The ports 11.0-11.3 are all upstream
• The precedence setting is 146 (within the remarking range)
• The name of the classifier is remark_mulitcast
officer SEC>> create class remark_multicast IPDEST=MULTICAST
officer SEC>> add action class remark_multicast SETVPRIORITY=4
officer SEC>> add class remark_multicast interface 11.0-11.3 precedence 146
officer SEC>> show class all
--- Classifier Configuration Data ---------------------------------------------
Name Field Match(es) Action(s)
------------------- -------------------------------------- -------------------
remark_multicast IPDEST= MULTICAST SETVPRIORITY=4
-------------------------------------------------------------------------------
officer SEC>> show class all int all full
--- Classifier Configuration Data ---------------------------------------------
Interface Rank Name Field Match(es) Action(s)
--------- ---- --------------- ------------------------------ ----------------
ETH:11.0 146 remark_multicast PROTOCOL= IPV4 (D) SETVPRIORITY=4
IPVERSION= 4 (D)
IPDEST= MULTICAST
ETH:11.1 146 remark_multicast PROTOCOL= IPV4 (D) SETVPRIORITY=4
IPVERSION= 4 (D)
IPDEST= MULTICAST
ETH:11.2 146 remark_multicast PROTOCOL= IPV4 (D) SETVPRIORITY=4
IPVERSION= 4 (D)
IPDEST= MULTICAST
-------------------------------------------------------------------------------
Note that when configuring classifiers, the FULL display for the classifiers for an interface will also include infor-
mation that has been derived from the classifiers. This will be shown with a (D) next to the classifier attribute.
Refer to the next subsection.
6.3.2.5 Derived Classifiers (D)
Note that when configuring classifiers, the FULL display for the classifiers for an interface will also include infor-
mation that has been derived from the classifiers. For example, a user has configured a classifier set as shown
below.
officer SEC> SHOW CLASSIFIER=ALL INTERFACE=2.0
--- Classifier Configuration Data -------------------------------------
Interface Rank Name Field Match(es) Action(s)
--------- ---- ---------------- --------------------------------- -----------
ETH:2.0 51 ip1 IPSOURCE=1.1.1.1/32
