Introduction XE4 Card Attributes
Software Reference for SwitchBlade x3100 Series Switches (Setting Up the Switch)
1-234
1.17.7 XE4 Card Attributes
The only common attribute for XE4 cards is the ADMIN STATE (UP or DOWN).
Note: If the user sets the Administrative State of the NM card to DOWN (using the DISABLE command
with the FORCE option) and there is only one NM provisioned, upstream data service is lost for the
SBx3112.
Following are the outputs for the Network Interfaces. (For details on the DIRECTION attribute, refer to
2.2.)
E134 - officer SEC>>>> SHOW INTERFACE DIRECTION=NETWORK
--- GE Interfaces ---
Interface State Autonegotiate Flow Control Duplex Speed Direction
----------- ----- ------------- ------------ ------ -------- ---------
3.22 UP-UP On Off Full 1 Gbps Network
3.23 UP-UP On Off Full 1 Gbps Network
10.16 UP-UP On On Full 1 Gbps Network
10.17 UP-UP On On Full 1 Gbps Network
--- XE Interfaces ---
Interface State Flow Control Direction
----------- ----- ------------ ---------
0.0 UP-UP Off Network
0.1 UP-DN Off Network
0.2 UP-DN Off Network
0.3 UP-DN Off Network
2.0 UP-DN Off Network
2.1 UP-DN Off Network
2.2 UP-DN Off Network
2.3 UP-DN Off Network
--- General Interfaces ---
Interface State Name
--------------- ----- ----------
ETH:0 UP-UP MGMT
Hardware Model Number
Serial Number
CLEI Code
The TN number for card type
The unique serial number for the card
The CLEI code, if the card has one.
Preferred SW Load Running
Preferred SW Load
Temporary SW Load
Refer to 1.10.
TABLE 1-48 Common Line Card Attributes - Defaults are in Bold) (Continued)
Card Attribute Values / Range Description
