Allied Telesis SwitchBlade x3100 Series User Manual

Feature / Component Interaction Introduction
1-223
Software Reference for SwitchBlade x3100 Series Switches (Setting Up the Switch)
1.16.3 Feature / Component Interaction
The components for the SBx3112 interfaces are divided into Service Modules and Control Modules.
Note: This table includes the ATN code where applicable to specify the card. For more information on these
cards, especially model numbers and compatible releases, refer to the Allied Telesis Component
Specification.
Controlling these components is done through the use of profiles, operational states, and provisioning modes,
as explained below.
Line Card Attributes Attributes common to all Line Cards 1.17.6
XE4 Attributes Attributes common to XE4 cards 1.17.7
TABLE 1-46 SBx3112 Cards
Component
Ty p e C o m p o n e n t
Model
Number Detail
Minimum
Software
Release
Chassis SBx3112-00 SBx3112-00 Chassis Group N/A
Cooling and
Power
FM4 SBx31FAN Fan Controller N/A
PoE Power Supply SBx3165 Up to two PSUs for Power over Ethernet
(PoE).
N/A
System Power Supply SBx3161 Up to two PSUs for 12V system power N/A
Service
Modules
GE24POE SBx31GP24 10/100/1000M with PoE 14.1
10G ports SBx31XZ4 XFP-based 10G interface 14.1
GE24SFP SBX31GS24 SFP-based 1G interface
Control
Modules
CFC200 SBx31CFC Provides 200G in load sharing mode, so
in duplex provides 400G throughput.
14.1
Filler Plate FPF Full-height -NA-
TABLE 1-45 Feature for the Provisioning of Modules (Continued)
Feature Description Refer to

Allied Telesis SwitchBlade x3100 Series Specifications

General

Brand	Allied Telesis
Model	SwitchBlade x3100 Series
Category	Switch
Language	English
