GE Interfaces Overview
Software Reference for SwitchBlade x3100 Series Switches (Interface Management)
2-4
Provisioning Provisioning Profile -
Profile that has been
applied to the card and if
there is a Profile mis-
match.
If there is a status mismatch, a (*) appears next to the Profile Name.
Direction Customer or Network. (Default is Customer.)
Auto Negotiation Specifies whether automatic negotiation of transmission parameters
for the ports is allowed.
If ON, the port has increased flexibility to communicate with the
remote peer. The port has the ability to advertise flow control and to
provide single direction fault coverage. The port will drive the link
state up and down based on the ability to communicate with the
remote peer, triggering on both transmit and receive failures Loss of
Signal (LOS).
If OFF, the port state is driven by receive failure (LOS). Flow control is
still provided as long as the FLOWCONTROL parameter is ON.
The default value is ON.
Speed 10, 100, 1000, AUTO (Default is AUTO.)
Duplex HALF, FULL, AUTO (Default is AUTO.)
Flow Control Specifies whether flow control is enabled. Note that flow control
works between the card and the external interface only; it does not
work across the backplane from card to card
If ON, the port can generate and respond to pause signals with the
remote peer.
If OFF, pause is ignored and not generated, and potential for packet
loss is increased.
FLOWCONTROL is independent of AUTONEGOTIATION.
If set to AUTONEGOTIATE, the port will respond to pause frames
from a remote peer. If set to OFF, pause is ignored and potential for
packet loss is increased. The SBX3112 does not generate pause frames.
True?
The default value is AUTO.
Remote monitoring On of Off
Actual Attributes measured
when the interface is
operationally UP.
Other attributes are determined by the Interface.
VLAN Informa-
tion
VLAN attributes The attributes for the VLAN over the interface.
TABLE 2-1 Interface Attributes for the GE24 Cards
Attribute Values/Range Description
