Allied Telesis SwitchBlade x3100 Series User Manual

GE24SFP Introduction
1-183
Software Reference for SwitchBlade x3100 Series Switches (Setting Up the Switch)
tions). Disabling the GE interface turns the activity LED off, regardless of whether a cable is present. Disabling
the GE interface has no effect on the POE LED.
1.12.6 GE24SFP
The GE24SFP card had 24 LEDs, one for each port, labeled L/A (for Link/Activity) on the faceplate. Each port
LED is used to indicate activity (green for a 1Gbps link, yellow for a 10/100 Mbps link, and flashing for activity).
The LED is OFF if the cable or SFP is missing. Disabling the XE interfaces turns the LED off, regardless of
whether a fiber is present.
1.12.7 LED Behavior
Color and pattern are used to distinguish the card states on the single LED per card. Green color indicates in
service or potentially in service (bootup) states, and amber color indicates out of service states. Thus, an amber
color indicates “Ok To Pull”. Solid light patterns are used to indicate stable states, while flashing patterns indi-
cate transient states. Table 1-32 illustrates the display of the slot status LEDs over various card states.
Note that when a card is reset, its LED is solid amber which is the same as the disabled state. The bootROM on
the card assumes that the card is disabled until told by the CFC to proceed with coming in service (which
involves transition to UP-DN-Loading or UP-DN-Booting). This policy ensures that a manually disabled card
continues to show solid amber even if a card is put into reset state by card insertion. It's also useful in visual
determination of reboot loops; in that case the card would continue to cycle between solid amber and flashing
TABLE 1-32 Single LED State for Card State on CFC200
Card State Slot LED State on CFC200
DN-DN-Offline Solid Amber
UP-DN-Reset Solid Amber
UP-DN-Offline (query) Solid Amber
UP-DN-Loading Flashing Green
UP-DN-Booting Flashing Green
UP-DN-Intest Flashing Green
UP-DN-Configuring Flashing Green
UP-UP-Online Solid Green
UP-UP-Degraded Flashing Amber
UP-DN-Failed Flashing Amber
UP-DN-NotInstalled (card mismatch) Solid Amber
UP-DN-NotInstalled (card not present) Off
No card physically present, no card provisioned Off
Inserted, not in database (manual provisioning mode) Solid Amber
