Introduction Configuring Classifiers

Software Reference for SwitchBlade x3100 Series Switches (Access and Security)

6-18

6.3.3 Configuring Classifiers

6.3.3.1 Default Configuration

When the SBx3112 is first installed and in service, there are no user-defined classifiers configured.

6.3.3.2 Configuration Guidelines

For the XE4, filtering on the DHCP packets can occur if the filter has only layer 2 fields in the match rules. So,

for example, if the user creates a classifier to block all traffic on VID=1, then DHCP requests on VID 1 are

blocked. However, if rules are created to allow certain IP addresses through, and all other IP addresses are

blocked, the DHCP packets can still get through because those layer 3 filters are not applied. This is done so

that the customer can get a valid IP address via DHCP.

6.3.3.3 Configuration Procedure

The general sequence to configure classifiers is to:

• Create the classifiers with a descriptive name and match rule.

• Associate actions to the classifiers, using COUNT as well when appropriate.

• Associate the classifiers to interfaces, including a PRECEDENCE, with the lower number receiving the

higher precedence.

The general sequence to deprovision a classifier is to:

• DELETE the classifier from the associated interfaces.

• DESTROY the classifier

In the following procedure, the user wishes to only allow traffic originated from a range of IP addresses, and to

drop any other packets.

TABLE 6-3 Configuration procedure for Classifiers

Step Command Description (Optional)

Create the classifiers and the allowed IP source (/ is for the mask)

CREATE CLASSIFIER=ipfilt1 IPSOURCE=192.168.1.0/24

CREATE CLASSIFIER=ipfilt2 IPSOURCE=10.0.0.0/24

CREATE CLASSIFIER=ipdrop IPSOURCE=ANY

Associate the classifiers with actions, with a COUNT for dropped packets
