Card Representation in Commands Introduction
1-3
Software Reference for SwitchBlade x3100 Series Switches (Setting Up the Switch)
1.2.2 Card Representation in Commands
For all of the cards except the power and cooling cards (refer to 1.15.1), a card is referenced by its slot number
(such as CARD=4). For CARD there is also ACTCFC and INACTCFC. Refer to SHOW CARD.
TABLE 1-1 Allied Telesis SBx3112 - Slot/Position and Configuration Notes
No. Module Slot/Position Configuration Notes
A Line Cards 0, 2, 6, 8, 10 (left)
1, 3, 7, 9,11 (right)
At least one is always configured. Unused slots must be config-
ured with a Filler Card.
In release 14.2, the cards available are:
- SBx31GP24 (GE24POE) - Power source for Power over
Ethernet (PoE) ports.
- SBx31XZ4 (XE4) - Provides four 10G SFP ports.
- SBx31GS24 (GEx24SFP) - Provides 24 1G SFP ports.
B SBx31CFC -
Control Fabric
Card
(CFC200)
4 (right)
5 (left)
When both slots are used, dual CFC200s provide redundancy.
Includes serial console and ethernet management ports, as
well as an SD card slot and USB interface.
Note: In release 14.2, when only one CFC200 is used,
the other slot must remain unused.
C SBx31FAN Fan Tray Slot Fan Controller. Varies fan speed depending on temperature
thresholds.
D AC POE PSU
(PSU)
Upper left of shelf
PSU Slots A and B
Allows up to two Power Supply Units (PSU) for Power over
Ethernet (PoE).
E AC System PSU Upper right of shelf
PSU slots C and D
Allows up to two PSUs for 12V system power
F ESD Bottom right of shelf ESD wrist strap connection point.
