Introduction LED Behavior
Software Reference for SwitchBlade x3100 Series Switches (Setting Up the Switch)
1-184
green. Once the application level software on the card is running and the bootROM is no longer in control, the
CFC will drive the LED states as per the table above.
The CFC activity LEDs are slightly different from iMAP devices, in that on iMAP systems the inactive CFC does
not light the activity LED at all, while on the x3112 the inactive CFC shows the amber color on its activity LED.
The inactive CFC activity LED is a solid amber pattern in all cases unless the card is online with the "Out of
Sync" alarm; in that case it has a flashing amber pattern. The active CFC booting up in simplex will set the M/S
LED to solid amber until the software determines activity status during initialization, then it turns to solid green
to indicate that the CFC is active.
When the CFC is in a stable state (either UP-UP-Online with no "Out of Sync" alarm, or DN-DN-Offline), nei-
ther the card status LED for that CFC nor the M/S LED is in a flashing state.
The following table illustrates the display of the Master/Slave LED over various states:
The following table illustrates the display of the PSU related LEDs over various states. Note that if any provi-
sioned PSU is in a failed state, then the single PSU LED on the CFC is flashing amber.
TABLE 1-33 CFC Card State and M/S LED on CFC200
CFC Card State M/S LED State (on corresponding CFC200)
UP-UP-Online (Active) Solid Green
UP-UP-Online (Inactive) - in sync Solid Amber
UP-UP-Online (Inactive) - out of sync Flashing Amber
UP-DN-
a
(Inactive)
a. Any transitional state
Solid Amber
DN-DN-Offline Solid Amber
TABLE 1-34 PSU States and Associated LEDs
PSU Card
State
PSU LED State
(on CFC200) AC LED (on PSU) DC LED (on PSU)
Fault LED (on
PSU)
UP-UP-Online Solid Green Solid Green Solid Green Off
UP-UP-
Degraded
Flashing Amber Solid Green Off
On
a
UP-DN-Failed
(output fault)
Flashing Amber Solid Green Off Solid Red
UP-DN-Failed
(no AC input)
Flashing Amber Off Off Off
