Allied Telesis SwitchBlade x3100 Series User Manual

Classifier Support on the SBx3112 Introduction
6-7
Software Reference for SwitchBlade x3100 Series Switches (Access and Security)
Following are notes related to this table:
• Classifiers on LAGs only support filtering and remarking; not metering.
• LAGs do not support egress port rate limiting.
Classifier Actions
DROP
X X X
FORWARD
X X X
COUNT
X X X
SETVPRIORITY
X X X
SETIPTOS
SETIPDSCP X X X
MOVEPRIOTOTOS
MOVETOSTOPRIO
Number of Egress Queues 8 8 8
Number of Classifiers
a
128 128 128
Number of Ingress Traffic Meters
192 192 32
Number of Ingress Traffic Counters
1200
b
(1176)
512(b) (508) 1920(b)
(1896)
Number of Out-of-profile Packet Meter Counters
192 192 32
a. Classifier capacity is an approximation. The features enabled on a port or interface, such as such as
IGMP, DHCPRELAY, VLAN (for per-VLAN UFO and HVLAN), EPSR, INTERFACE (TAGALL
option for HVLAN), ACCESSLIST, and CLASSIFIER, classifiers on surrounding ports, content of the
user classifiers, and many other factors influence the number of classifiers available on a given port or
interface.
b. The number of ingress traffic counters is limited by the current total number of available classifiers.
The maximum possible classifiers is shown in the above table. BFD always consumes 1 classifier per
external port (24 for the GE24POE and GE24SFP, and 4 for the XE4), so the maximum attainable by
customer is contained in parentheses.
TABLE 6-1 Traffic Management Summary Table - Cards on the SBx3112
Classifier Match Fields GE24POE GE24SFP XE4
