Introduction Classifier Management
Software Reference for SwitchBlade x3100 Series Switches (Access and Security)
6-16
officer SEC>> show class all int 3.4 full
--- Classifier Configuration Data ---------------------------------------------
Interface Rank Name Field Match(es) Action(s)
--------- ---- ------------ ---------------------------------------- ---------
ETH:3.4 51 ips1 (NORES) IPSOURCE=10.10.10.1/32
52 ips2 (NORES) IPSOURCE=10.10.10.2/32
53 ips3 (NORES) IPSOURCE=10.10.10.3/32
54 ips4 (NORES) IPSOURCE=10.10.10.4/32
55 ips5 (NORES) IPSOURCE=10.10.10.5/32
56 ips6 (NORES) IPSOURCE=10.10.10.6/32
57 ips7 (NORES) IPSOURCE=10.10.10.7/32
58 ips8 (NORES) IPSOURCE=10.10.10.8/32
59 ips9 (NORES) IPSOURCE=10.10.10.9/32
60 ips10 IPSOURCE=10.10.10.10/32
(NORES)
61 ips11 IPSOURCE=10.10.10.11/32
(NORES)
62 ips12 IPSOURCE=10.10.10.12/32
(NORES)
63 ips13 IPSOURCE=10.10.10.13/32
(NORES)
68 ipdrop PROTOCOL=IPV4 DROP
(NORES) COUNT
-------------------------------------------------------------------------------
officer SEC>> show alarm card 3
--- Interface(Port) Alarms ---
Interface Fault Severity Time Stamp
------------ -------------------------------- -------- --------------
3.4 Classifier Resource Failed Minor 03:17:56 08/04
6.3.2.9 Error (ERR)
This error would occur in the instance of a software error. This would be different from a NOSPT or NORES.
In the example below, the user has added three classifiers to a port and attempts to add a fourth. An error
appears saying the card cannot accept the fourth classifier because the number of masks supported by the card
has been exceeded. As a result, when the user displays the classifiers for the port a No Resources error
appears next to the classifier. The user can delete the fourth classifier and the (ERR) is removed from the dis-
play.
officer SEC> ADD CLASSIFIER=ip1 PORT=11.0 PRECEDENCE=51
Info (010017): Operation Successful
P
officer SEC> ADD CLASSIFIER=ip2 PORT=11.0 PRECEDENCE= 52
Info (010017): Operation Successful
officer SEC> ADD CLASSIFIER=ip3 PORT=11.0 PRECEDENCE= 53
Info (010017): Operation Successful
officer SEC> ADD CLASSIFIER=ip4 PORT=11.0 PRECEDENCE= 54
Info (010017): Operation Successful
officer SEC> SHOW CLASSIFIER=ALL PORT=11.0
--- Classifier Configuration Data ---------------------------------------------
Port Rank Name Field Match(es) Action(s)
---- ---- ---------------- --------------------------------- -----------------
11.0 51 ip1 (ERR) IPSOURCE=1.1.1.1/1
52 ip2 (ERR) IPSOURCE=1.1.1.1/2
53 ip3 (ERR) IPSOURCE=1.1.1.1/3
54 ip4 (ERR) IPSOURCE=1.1.1.1/4
145 telesyn_default_ IPDEST=MULTICAST SETVPRIORITY=1
video (ERR)
-------------------------------------------------------------------------------
