Introduction Configuring RMON Ethernet Statistics

Software Reference for SwitchBlade x3100 Series Switches (Network Management)

7-100

ADD / DELETE / SET INTERFACE RMONALERT

Syntax

ADD INTERFACE={ type:id-range | id-range | ifname-list | ALL }

RMONALERT { DROPEVENTS | OCTETS | PACKETS | BROADCAST | MULTICAST |

| PKTS64OCTETS | PKTS65TO127OCTETS | PKTS128TO255OCTETS |

PKTS256TO511OCTETS | PKTS512TO1023OCTETS | PKTS1024TO1518OCTETS } {

ABSOLUTE | CHANGE }

{ INTERVAL=2..3600

RISINGTHRESHOLD=threshold FALLINGTHRESHOLD=threshold }

Description Allows a user to specify threshold alarm settings for an Ethernet statistic on a specified

interface. The supported Remote Monitoring (RMON) statistics for Ethernet interfaces

are based on the RMON MIB (RFC2819). Samples are taken on an interval basis and

compared to the provided thresholds. A management log and an SNMP trap are gener-

ated when either the rising or falling threshold is crossed.

The DELETE INTERFACE RMONALERT command allows a user to delete threshold

alarm settings for an Ethernet statistic on a specified interface.

The SET INTERFACE RMONALERT command allows a user to modify threshold alarm-

ing settings for an Ethernet statistic on a specified interface.

Options The following table gives the range of values for each option that can be specified with

this command and a default value (if applicable).

Option Description Default Value

INTERFACE A logical representation of one or more physical ports;

the INTERFACE for which RMON data is enabled

type:id-range - the type of available ports, such as

ETH:7.0 or a range (ETH:8.0-8.9)

id-range - used with type (type:id) to query the physical

ports; the numerical identifier of the interface

ifname-list - list of interface names, if not numerical

ALL - used to specify the same historical data collection

parameters on all applicable interfaces in the system
