IGMP Trace IGMP Counters
Software Reference for SwitchBlade x3100 Series Switches (Alarms and Troubleshooting)
8-26
PIMV2 0 0
-------------------------------------------------------------------------------
Info (010017): Operation Successful
• Example output of IGMP counters for a specified interface.
officer SEC> SHOW IGMP COUNTER INTERFACE 1.4
--- IGMP Interface-Level Message Counters -------------------------------------
Interface Message Type Good Count Error Count
---------- -------------- -------------- --------------
5.4 Report 0 0
Leave 0 0
General Query 0 0
OSPF 0 0
DVMRP 0 0
PIMV1 0 0
PIMV2 0 0
Info (010017): Operation Successful
An IGMP MESSAGERESPONSE output contains the following fields:
• Counter - Eight counters (buckets) are supported.
• Response Range - Each counter tracks an individual response range from 0-4+ seconds.
• Last Updated - Timestamp indicating the last time the count was incremented.
• Message Count - The number of messages that have experienced <Response Range> delay across IGMP
message queue.
The example IGMP MESSAGERESPONSE output follows:
officer SEC> SHOW IGMP COUNTER MESSAGERESPONSE
--- IGMP System-Level Message Response Counters -------------------------------
Counter Response Range Last Updated Message Count
-------- -------------------- ---------------------- --------------
0 0-249 (msec) 2004-04-06 06:08:56 38412
1 250-499 (msec) 2004-04-05 19:25:03 38
2 500-749 (msec) 2004-04-05 19:24:59 0
3 750-1000 (msec) 2004-04-05 19:24:59 0
4 1-2 (sec) 2004-04-05 19:24:59 0
5 2-3 (sec) 2004-04-05 19:24:59 0
6 3-4 (sec) 2004-04-05 19:24:59 0
7 4+ (sec) 2004-04-05 19:24:59 0
Info (010017): Operation Successful
An IGMP COUNTER STANDARD output contains the following fields:
• Message Type - Seven message types currently processed by IGMP.
• Good Count - Number of <Message Type> messages that were processed to completion.
• Error Count - Number of <Message Type> messages that were not processed to completion.
The example IGMP MESSAGERESPONSE output follows:
officer SEC> SHOW IGMP COUNTER STANDARD
--- IGMP System-Level Message Counters ----------------------------------------
Message Type Good Count Error Count
-------------- -------------- --------------
Report 230 0
Leave 110 15
General Query 6 0
OSPF 1 0
DVMRP 0 0
PIMV1 0 0
