• Remove an existing ECM
Control scrambling of an output service. The output triplet (Net ID, TS ID, and SID) is used as the output service
identifier.
As the EIS is not able to create the ECMG channel configuration, this needs to be done from the web GUI before
the EIS can be used.
Based on the DVB Simulcrypt standard, only one EIS is permitted per chassis.
To establish a connection to an EIS service, go to Scrambler → SCS → EIS node in the Navigation Tree, enter
appropriate values and click Add.
The following information is displayed:
Logical port representing the connection to the EMMG – assigned
automatically. This number is used internally as well as for generating
alarms.
For reference in the GUI only
IP address of the EIS service to be connected to
TCP port for the EIS to connect to
To change an, EIS connection, click on the existing EIS entry and enter the new configuration.
