FEC
Enable if input stream has IP FEC present
IP Address
IP address of the multicast or unicast
Port
UDP Port of the multicast or unicast
VLAN
Name of VLAN (if enabled)
IGMPv3/SSM
Enable or disable IGMPv3/SSM on the port, Please see Error! Reference source not f
ound. for more information and options
Dejitter
If input de-jittering is enabled, the following options are displayed:
o PCR. This is automatic for regular streams
o Preferred PCR PID. This allows you to set a PCR PID in the input multiplex as a
priority to use for de-jittering. If this PID is not available, then the next valid
detected PCR will be used. This is only valid for transparently mapped streams.
o CBR (if transparent). This de-jitter mechanism will use the incoming CBR total
bitrate as a guide for the clock source of the stream. This is only valid for
transparent mapped and PID imported outputs.
This feature is only available on the Switch+IP module.
Reduced Input
Buffer
Enable or disable Reduced Input Buffer for introducing a low latency IP dejitter function
on the Switch+IP and Dual IP modules.
The status parameters for the IP module are shown below.
The following parameters are available:
Sync
Interval of the sync byte, usually 188
Effective Bitrate
Effective bitrate of the input stream
Total Bitrate
Total bitrate of the input stream
Active Source
IP address for the MPTS/SPTS source (Used for IGMP v3)
