– Open cover of mounting -2- and hold in this position.
– Insert puller - T40148- into 12 V socket -3- as far as stop.
– Turn knurled wheel -1- on puller - T40148- clockwise as far as
stop.
• The piston -2- moves upwards and the release tabs -1- on
puller - T40148- spread apart -arrows-.
– Take 12 V socket out of mounting.
– Unplug electrical connector.
Installing
Installation is carried out in the reverse order; note the following:
– Detach support -1- from puller - T40148- .
– Push piston downwards and hold in this position.
– Turn knurled wheel -4- on puller - T40148- anti-clockwise
-arrow-; this will open release tabs -2- on 12 V socket -3- and
puller - T40148- can be removed.
Audi A8 2003 ➤
Electrical system - Edition 08.2014
104 Rep. gr.90 - Gauges, instruments
