– Do not flash the headlights.
– Remove appropriate front wheel.
– Remove relevant front wheel housing liner ⇒ Rep. gr. 66 .
Headlight (right-side) - vehicles with auxiliary heater:
– Unscrew bolt -arrow- for coolant pipe -1- and lock carrier.
All vehicles (continued):
– Loosen locking bolt -1- a few turns.
– Release retaining tabs -arrows- and detach housing cover for
dipped beam headlights from headlight housing.
– Check position of adjustment lever -1- at both headlights.
• Lever down = Driving on left
• Lever up = Driving on right
– If necessary, swivel lever until it engages in desired position
-arrow-.
– Close housing cover and secure with locking bolt.
– Install front wheel housing liner ⇒ Rep. gr. 66 .
4.24 Adapting headlights for driving on the
left or right side of the road - vehicles
without adjustment lever
When travelling in countries where the vehicle is to be driven on
the other side of the road, both headlights must be adjusted to
prevent dazzling by the asymmetric dipped beam.
Procedure
– The headlights can be adapted for driving on the left or right
using the “Headlamp converter” function ⇒ Vehicle diagnostic
tester.
Audi A8 2003 ➤
Electrical system - Edition 08.2014
4. Gas discharge headlights 175
